The dust-free feature not only makes the tube more accurate in the tube rolling process and prolongs the life of the tube rolling machine, it can also avoid the waste of magnesium powder and protects the health of employees to the greatest extent; tri-centering guaranteed design make sure the heating wire in the center of pipe during the powder filling process, thereby reducing eccentric and leakage. In addition, its resistance performance is very high, as it adopts the magnesium Oxide manufacturing technology to make the thicknesses to be uniformed, so as to ensure that the proportion of the powder particle filled is uniform, and the error of rolling tube length is minimized.

The main technical parameters:

Power supply:

•Non-following models: single-phase 220V/50Hz, 1.5kW

•Following models: single-phase 220V/50Hz, 2.0kW

Air source: 0.5~0.7MPa

Processed pipe diameter: Ф6~Ф20 (customized specifications)

Processing length: (The following are commonly used models and other models are customized)

007 100-700mm

010 300-1000mm

016 400-1600mm

020 400-2000mm

Processing quantity/time (number of stations) 33 pieces (determined by pipe diameter, can be customized according to demand)

Powder filling rising speed: 200~300mm/min (adjustable by frequency conversion)

Oscillation mode: follow or fixed mode (optional)

Filling density: ≥2.25/cm

The way of centering guarantee: 3 conduits

Control method: man-machine interface

Production efficiency: about 6000/7000 10 hours (calculated at 33 stations 300mm) The speed can be adjusted according to the customer's requirements for the magnesium powder density of the tube.
